Lightweight portable mini pump
Lightweight portable mini pump Type MPS
The MPS is a handy portable air driven mini pump that can be easily carried, even on stairs, because of its weight (less than 17 kg with a filled tank) and size (405x308x365 mm). Although this mini pump is small in size and low in weight it is very suitable for the pressure testing of objects for pressure ranges up to 1800 bar at 7 bar air drive pressure and 2500 bar at 10 bar air drive pressure.
Through its pressure supply capacity, it is possible to manually drive the pump through a detachable hand lever if you are in a situation when air pressure is not available. The medium for pressurizing objects with this test system can be a fluid such as water or oil.
- Lightweight, easy to carry
- Suitable for pressurizing oil, water or other fluids
- Completely closed frame
- All operating features panel mounted
The testing of objects with the MPS can be efficiently done, because all operating features are panel mounted. Another feature that makes the MPS a high functional pump is that all components, including the required connecting materials and tubing, are mounted in a solid plastic closed frame. This completely closed frame ensures that the pump can be used under more severe conditions, because the pump is not susceptible to for example dirt or water. Furthermore, all parts of the pump are made of non-corrosive materials, which give the pump and separate parts a longer lifetime.
|Max. operating pressure||2.500 bar|
|Max. air drive pressure||10 bar|
|Max. flow||1.10 l/min|
|Noise level||< 80 dBa|
